Die Grinder Bits Carbide Grinding Burrs T Type Special Carbide Burrs
100 PIECES
MOQ
$0.80 - $5.00/piece
Price
Die Grinder Bits Carbide Grinding Burrs T Type Special Carbide Burrs
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Sichuan, China
Brand Name: KTS
Certification: ISO9001-2008
Model Number: Customized
High Light:

tungsten carbide rotary burrs

,

rotary burr cutter

Payment & Shipping Terms
Packaging Details: Plastic Case
Delivery Time: 7-15 Days
Payment Terms: T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability: 250000 Piece/Pieces per Month
Specifications
Materials: Tungsten Carbide
Grade: YG10X
Color: Silver
LOGO: Customized
Sample: Supplied
Size: 3-25mm
Type: T Type
Shank: 40-230MM
Product Description

Carbide Burr Die Grinder Bits Carbide Grinding Burrs T Type Burrs Special Carbide Burrs





RECOMMENDATIONS FOR USE:



Tungsten Carbide Burrs are designed for machining materials of virtually any strength; the superior performance reflects an optimum combination of key parameters such as shape, number of flutes, spiral angle, rake angle and concentricity. The precise concentricity of  tungsten carbide burrs

• Ensures an improved protection of operator safety and health

• Reduces power tool wear

• Provides smooth operating behaviour

• Prevents chatter marks



An optimum power output and RPM of the power source (air-powered or electric machine, flexible shaft system) are necessary conditions for an economically efficient use of tungsten carbide burrs. We therefore recommend you to observe the following rules:

• Work with maximum RPM. Do not use speeds below 3000 RPM except in special cases (eg: on stationery machines or when countersinking with fully immersed burr).

• Chucks and collets must be absolutely concentric to avoid chipping. Tool runout and chatter will result in premature wear.

• Work with significantly reduced RPM on poorly heat conducting materials (eg: stainless steel, titanium alloys, etc.) to prevent tool damage. Avoid the typical blue Discoloration of the shank and the tool.

• In light cutting applications (deburring, chamfering, light surface work) the tool speed may be increased uo to twice indicated rate.

• When machining very sticky materials, the use of a suitable lubricant (grease, kerosene, chalk or similar) is recommended to prevent loading.



We manufacture and specialize in carbide burr die grinder bits.

Tungsten carbide burrs can be used on most hard materials including steel, aluminum and cast iron, all types of stone, ceramic, porcelain, hard wood, acrylics, fibreglass and reinforced plastics. When used on soft metals such as gold, platinum and silver, carbide burrs are perfect as they will last for a long time with no breaking or chipping.

Different cuts of carbide burrs will be best suited for certain materials. We offer carbide burrs on 1/4″ shanks, solid carbide burrs, 1/4″ burrs on 1/8″ shanks, long shank burrs, NF carbide burrs, carbide burr sets, end mills and accessories.

What can our Carbide Burr Tools be used for?

Our carbide burrs are used in air tools such as die grinders, pneumatic rotary tools and high speed engravers. Micro Motors, Pendant Drills, Flexible Shafts, and hobby rotary tools such as a Dremel.

Carbide burrs are widely used for metalworking, tool making, engineering, model engineering, wood carving, jewelry making, welding, chamferring, casting, deburring, grinding, cylinder head porting and sculpting. Carbide burrs are used in the aerospace, automotive, dentistry, stone and metalsmith industries.

Die Grinder Bits Carbide Grinding Burrs T Type Special Carbide Burrs 0
