Size Ref. |
Cut Dia | Overall Length | Cut Length | Shank Dia | Item(1/4“Shank) |
Item (6mm Shank) |
|
Double Cut |
||||||
| SE410 | 1/8 | 1-1/2 | 7/32 | 1/8 | B203 SE410 | |
| SE510 | 1/4 | 2-1/8 | 3/8 | 1/8 | B203 SE510 | B303 SE510 |
| SE100 | 1/4 | 2 | 3/8 | 1/4 | B203 SE100 | B303 SE100 |
| SE300 | 3/8 | 2-11/32 | 19/32 | 1/4 | B203 SE300 | B303 SE300 |
| SE500 | 1/2 | 2-5/8 | 7/8 | 1/4 | B203 SE500 | B303 SE500 |
| SE600 | 5/8 | 2-3/4 | 1 | 1/4 | B203 SE600 | B303 SE600 |
| SE700 | 3/4 | 2-3/4 | 1 | 1/4 | B203 SE700 | |
| Aluminium Cut | ||||||
| SE3AC | 3/8 | 2-11/32 | 19/32 | 1/4 | B218 SE3AC | |
| SE5AC | 1/2 | 2-5/8 | 7/8 | 1/4 | B218 SE5AC | |
| SE6AC | 5/8 | 2-3/4 | 1 | 1/4 | B218 SE6AC | B318 SE6AC |
Advantage:
• Better stock removal rate than burrs with a conventional cross cut.
• Significantly Saves money and time through its very high stock removal rate on key materials.
• Comfortable working with reduced vibration and less noise.
Materials that can be worked:
• Steel, cast steel
• Stainless steel (INOX)
• Non-ferrous metals
• Cast iron
Applications:
• Milling outLevelling
• Deburring
• Cutting out holesSurface workWork on weld seams
Notes
• It may be necessary to adjust the rates shown to achieve optimum performance.
• Harder materials require slower speeds.
• Smaller burs require faster speeds.
• Extra long burs (>150mm long) require slower speeds.
• Apply constant movement and light pressure when in use.
• Running below the optimum speed will encourage chipping.
• Running above optimum speed will cause tooth wear.
• Allowing the tool to become too hot may cause the braze to melt and detach the head from the shank.
• Using tools and collets that have become worn will encourage chipping.
• Do not sink the bur for more than one third of its periphery.
• Non-ferrous metals.
