Cone Head Tungsten Carbide Burr Bits High Efficiency Rotary Tool Bits
10 Piece/Pieces
MOQ
$1.00 - $12.00 / Pieces
Price
Cone Head Tungsten Carbide Burr Bits High Efficiency Rotary Tool Bits
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Sichuan, China
Brand Name: KTS
Certification: ISO9001:2008
Model Number: Customized
High Light:

tungsten carbide grinding bit

,

long shank carbide burr

Payment & Shipping Terms
Packaging Details: Plastic box in Standard export carton
Delivery Time: 7-15 Day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 250000 Piece/Pieces per Month
Specifications
Product Name: Tungsten Carbide Rotary Files
Type Of Cut: Standard Double-cut,fine Cut,fine Double-cut,etc.
Material: Tungsten Carbide
Grade: YG 8
Size: Full Size
Shape: Cone
LOGO: Customized
Sample: Supplied
Certificate: ISO9001:2008
Business Type: Manufacture & Trade Integration
Port: SHANGHAI/ BEIJING/ NINGBO/ YIWU/ GUANGZHOU(CANTON)/ QINGDAO/ CHENGDU
Product Description

Cone Head Carbide Burrs High-Efficiency Tungsten Hand Tool Rotary Burr



Name
Type
Cut
Material
Product Process
Head Hardness
LOGO
Cylindrical
A
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Cylindrical End Cut
B
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Cylindrical Radius End
C
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
BALL SHAPE
D
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Oval
E
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Tree Shape
Radius End
F
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Tree Pointed Ends
G
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Flame
Shape
H
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
60°Cone
J
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
90°Cone
K
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Taper Radius End
L
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Cone
M
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Inverted Cone
N
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available
Disc Type
W
Standard/Single/Double/aluma
Tungsten carbide/YG7/TCT
CNC
90-91HRA
available

Carbide burs/porting tools for metal working. Manufactured on premium automated CNC machines, carbide burs are available in three main styles of cuts – single, double and aluma.
Single-cut burs are for general purpose work and provide good material removal.
Double-cut burs produce smaller chips for greater operator control on applications such as stainless steels and ferrous materials.
Aluma-cut burs have a wide flute design for easy stock removal without loading on applications such as nonferrous and soft materials.
Standard-cut burs are widely uesed and leave a fine finish
The carbide bur line includes more than 175 individual burs and one 10-piece kit and 5-piece kit. Overall bur lengths range carbide burs are used in many industries including automotive, aerospace, foundry, power station and engineering for mold and pattern making, die sinking, tool making and maintenance.






How to use the carbide burrs

1.Speed /RPM

The speed at which you use your carbide bur in your rotary tool will depend on the material you're using it on and the contour being produced but it's safe to say you do not need to exceed speeds of 35,000 RPM. The table below shows some approximate speeds.
Diameter of Burr RPM
2.35mm or 3/32" 17,000 - 26,000
3mm or 1/8" 17,000 - 26,000
6mm or 1/4" 11,000 - 16,500
12mm or 1/2" 8,000 - 12,000
16mm or 5/8" 7,650 - 11,500
2.Apply only a little pressure
As with all drill bits and burrs, let the burr do the work and apply only a little pressure otherwise the cutting edges of the flutes will chip away or become smooth too quickly, reducing the life of your burr.
3.Keep The Carbide Burr On The Move
When using your carbide burr try not to keep it still for too long as this will prevent the burr from digging and jabbing into your material causing unsightly marks and roughness.



Advantage of our carbide burrs

·100% quality and brand new.
·Can Process a variety of metal and non-metal, processing hardness would up to HRA89-92.5
·In a great part of the work, it can replace the petiole small wheel, and no dust pollution.
·High production efficiency, the processing efficiency is several times higher than file, nearly 10 times higher than small wheel stalk.
·High product processing quality, high finish, can process out a various of high-precision mold cavity.
·Long life, the durability is 10 times higher than high-speed steel cutting tool, 200 times higher than small grinding wheel.
·Easy to use, safe and reliable, can reduce labor intensity, improve the working environment.
·Suitable for processing these metal and non-metal, such as cast iron, cast steel, bearing steel, high carbon steel, chrome-nickel alloy, bronze, brass, and ceramic tile, marble, jade, bone, etc.



Cone Head Tungsten Carbide Burr Bits High Efficiency Rotary Tool Bits 0
Product Application
Tungsten carbide burr is used widely in the shipping construction, auto engine porting and foundry fabrication. With its high rotating speed and hardness, it can machine a lot of different materials like cast iron, carbon steel, alloy steel and non ferrous material. High life service of product is warranted for virgin and excellent raw material which is one of most critical factors to the tools' life.
