Rainbow Carbide DLC Coated End Mills Fresas CNC Milling Cutter For Aluminum/Copper

100pcs
MOQ
$1-20
Price
Rainbow Carbide DLC Coated End Mills Fresas CNC Milling Cutter For Aluminum/Copper
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Rainbow Color DLC Coating Carbide Endmill
Diameter: 1.0mm To 22.0mm,D 1 - 25mm
Hrc: 45/55/60/65 HRC
Suitable For: Carbon Steel,Stainless Steel,copper
Precision: High Precision,ISO Standard
Flutes: 1-10F
Type: Tungsten Carbide Milling Tool For Steel
Oem: OEM Is Hot Welcome
Highlight:

Carbide DLC coated end mills

,

Rainbow Color dlc end mill

,

DLC CNC Milling Cutter

Basic Infomation
Place of Origin: SICHUAN, CHINA
Brand Name: KINGTOOLS
Certification: ISO 9001
Model Number: 4F-10*25*10*75
Payment & Shipping Terms
Packaging Details: Platic box & carton
Delivery Time: 7-15
Payment Terms: L/C, , T/T, Western Union, MoneyGram
Supply Ability: 20000PCS PER MONTH
Product Description

Rainbow Color DLC Coating Carbide Endmill Fresas CNC Milling Cutter For Aluminum/Copper



Product Introduction:



4 flutes:

high rigidity, widely used in shallow slot, profile milling, and finish maching.



35 deg:

high adaptability to the material and hardness of workpieces, widely used to mold and product processing and cost efficient.



Rainbow Carbide DLC Coated End Mills Fresas CNC Milling Cutter For Aluminum/Copper 0



Specification:



Name: END MILLS

Material: 100% raw material carbide
Metrial: Tungsten Carbide
Coating: HRC45° HRC50° HRC55° HRC60° HRC65°
Flute:1Flute 2Flute 3Flute 4Flute 5Flute End Mills




About Coatings:



Endmill Grade
Coating Name
Color
Hv
μm
Friction
The MaxºC
Application
HRC 45° coating
AlTiN
black
3300
0.6
0.7
850ºC
Suitable for General Steel
HRC 50° coating
AlTiN
black
3300
0.6
0.7
850ºC
Suitable for General Steel
HRC 55° coating
TiSiAlN
bronzed
3400
0.5
0.7
900ºC
General Steel,cast cast iron
HRC 60° coating
AlCrSiN
black
4000
0.4
0.35
1100ºC
High Hard Material, steel, cast iron, etc
HRC 65° coating
nACo 3 Blue
blue
4500
0.4
0.45
1200ºC
Titanium Alloy, High-temperature Alloy,material, etc
HSS
nACo 3 Blue
Other
4500
0.4
0.45
1200ºC
Stainless steel
Free Sample Test : Contact Us For Inquiry





Product Catalog:

Rainbow Carbide DLC Coated End Mills Fresas CNC Milling Cutter For Aluminum/Copper 1



Product Sizes:



D1 (Diameter of cut)
d (Shank Diameter)
L (Flute Length)
L1 (Overall Length)
1mm
4mm
3mm













50mm
1.5mm
4mm
4mm
2mm
4mm
6mm
2.5mm
4mm
8mm
3mm
3mm
8mm
3mm
4mm
8mm
3.5mm
4mm
11mm
4mm
4mm
11mm
1mm
6mm
3mm
1.5mm
6mm
4mm
2mm
6mm
6mm
2.5mm
6mm
8mm
3mm
6mm
8mm
3.5mm
6mm
11mm
4mm
6mm
11mm
4.5mm
6mm
13mm
5mm
5mm
13mm
5mm
6mm
13mm
6mm
6mm
15mm
7mm
8mm
20mm
8mm
8mm
20mm
9mm
10mm
25mm

75mm
10mm
10mm
25mm
12mm
12mm
30mm
14mm
14mm
45mm


100mm
16mm
16mm
45mm
18mm
18mm
45mm
20mm
20mm
45mm





Production Process:



Rainbow Carbide DLC Coated End Mills Fresas CNC Milling Cutter For Aluminum/Copper 2





Package & Shipping:

Rainbow Carbide DLC Coated End Mills Fresas CNC Milling Cutter For Aluminum/Copper 3





Our Advantages:

Suitable for finishing,can achieve the mirror effect.
coating increase surface gloss,and prolonging life.
100% quality guarantee (ISO9001)
Work material: carbide steel, alloy steel, cast iron, copper, mould steel,etc.
100% original tungsten, without recycle parts. Wc90%, Co10%, more cobalt will make end mills more crisp.

Our Company:
Rainbow Carbide DLC Coated End Mills Fresas CNC Milling Cutter For Aluminum/Copper 4

FAQ:


1) When can I get the price?

We usually quote within 24 hours after we get your inquiry.If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.



2) How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality. If you just need a blank sample to check the design and paper quality, we will provide you sample for free, as long as you afford the express freight.



3) How long can I expect to get the sample?

After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.



4) How long does the whole procedure being worked out?

After you place a order,the production handling time is about 45-60 days. We need 15 days to prepare all the stuff then 30 days for manufacturing.



5) What about the transportation and delivery date?

Normally we use shipment to transprot the goods.It is about 25-40 days.It also denpends on which coutry and port you are.It could be shorter if you need to send the goods like Asian. If there are some emergencies we can send the goods via air express, as long as you afford the traffic expense.



6) Are you trading company or manufaturer?

We are professional manufacturer. We not only owns our tools factory, but also have cemented carbide factory.



7) Where is your factory located?

We are located in Weishanhu Road 100, Xixiashu Town, New North District, Changzhou City, Jiangsu, China.



8) How long can I expect to get the sample?

After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.



9) How about your stock?

We have large quantity products in stock, regular types and sizes are all in stock.



10) Is free shipping possible?

We don't offer free shipping service. We can have a discount if you buy a large quantity products.
