YG6 Tungsten Carbide Burr Set for Die Grinder All Shapes

YG6 Tungsten Carbide Burr Set for Die Grinder All Shapes

Brand Name:	KTS
Model Number:	ALL TYPES
MOQ:	50 SETS
Price:	15-25USD/SET
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	250000 PIECES PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

SICHUAN, CHINA

Certification:

ISO9001:2008

Shape:

ALL SHAPES

Name:

TUNGSTEN CARBIDE BURRS

Size:

Full Size

Grade:

YG6

LOGO:

Customized

Trial Order:

Acceptable For Any Quantity

Shank:

40 CrMo

Type Of Cut:

SINGLE CUT, DOUBLE CUT, ALUMINUM CUT

Port:

SHANGHAI

Packaging Details:

CARTON

Highlight:

Trial Order Tungsten Carbide Burr Set

YG6 Grade Tungsten Carbide Burr Set

Die Grinder Tungsten Carbide Burr Set

Product Description

Trial Order Acceptable Metric Tungsten Carbide Burr Set For Die Grinder Drill Bits YG6 Grade

Product Specifications

Attribute	Value
Shape	ALL SHAPES
Name	TUNGSTEN CARBIDE BURRS
Size	Full size
Grade	YG6
LOGO	Customized
Trial Order	Acceptable for any quantity
Shank	40 CrMo
Type of Cut	SINGLE CUT, DOUBLE CUT, ALUMINUM CUT
Port	SHANGHAI

Product Details

Product name: Tungsten Carbide Rotary Files
Shank diameter: 3mm/6mm/8mm
Brand: KTS
Packing: Set packing
Shank hardness: HRA 89-92.5
Speed of tool: 15000-45000 Turn/min
Material: Tungsten Carbide
Certificate: ISO9001:2008

Material: 100% of raw materials
Tolerance: Strict tolerance extent control, which can reach +/-0.01mm
Grades: Various for choice: YG6, YG8, YG8C, YG11C, YG15C and so on
Types: Standard, conical, parabolic, ballistic
Physical performance: High hardness and impact toughness, very good mechanical & chemical stability

Available Types and Specifications

Name	Type	Cut	Material	Product Process	Head Hardness	LOGO
Cylindrical	A	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Cylindrical End Cut	B	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Cylindrical Radius End	C	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
BALL SHAPE	D	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Oval	E	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Tree Shape	F	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Tree Pointed Ends	G	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Flame	H	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
60°Cone	J	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
90°Cone	K	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Taper Radius End	L	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Cone	M	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized
Inverted Cone	N	Standard/Single/Double/aluma	YG6/YG8/YG10X/YG20C	CNC	89-92.5HRA	Customized

How to Use the Carbide Burr

1. Speed /RPM
The speed at which you use your carbide bur in your rotary tool will depend on the material you're using it on and the contour being produced but it's safe to say you do not need to exceed speeds of 35,000 RPM. The table below shows some approximate speeds.

Diameter of Burr	RPM
2.35mm or 3/32"	17,000 - 26,000
3mm or 1/8"	17,000 - 26,000
6mm or 1/4"	11,000 - 16,500
12mm or 1/2"	8,000 - 12,000
16mm or 5/8"	7,650 - 11,500

2. Apply only a little pressure
As with all drill bits and burrs, let the burr do the work and apply only a little pressure otherwise the cutting edges of the flutes will chip away or become smooth too quickly, reducing the life of your burr.

3. Keep The Carbide Burr On The Move
When using your carbide burr try not to keep it still for too long as this will prevent the burr from digging and jabbing into your material causing unsightly marks and roughness.

Advantages of Our Carbide Burrs

100% quality and brand new
Can process a variety of metal and non-metal, processing hardness would up to HRA89-92.5
In a great part of the work, it can replace the petiole small wheel, and no dust pollution
High production efficiency, the processing efficiency is several times higher than file, nearly 10 times higher than small wheel stalk
High product processing quality, high finish, can process out a various of high-precision mold cavity
Long life, the durability is 10 times higher than high-speed steel cutting tool, 200 times higher than small grinding wheel
Easy to use, safe and reliable, can reduce labor intensity, improve the working environment
Suitable for processing these metal and non-metal, such as cast iron, cast steel, bearing steel, high carbon steel, chrome-nickel alloy, bronze, brass, and ceramic tile, marble, jade, bone, etc.

Tungsten carbide burr is used widely in the shipping construction, auto engine porting and foundry fabrication. With its high rotating speed and hardness, it can machine a lot of different materials like cast iron, carbon steel, alloy steel and non ferrous material. High life service of product is warranted for virgin and excellent raw material which is one of most critical factors to the tools' life.
