Flame Carbide Burr
Created with Pixso.

Weld Rough Edges Flame Carbide Burr Polishing Carbide Burr Tool

Weld Rough Edges Flame Carbide Burr Polishing Carbide Burr Tool

Brand Name: KTS
Model Number: SH
MOQ: 20 Piece/Pieces
Price: USD 1-10 Piece/Pieces
Payment Terms: L/C,D/A,D/P,T/T,Western Union,
Supply Ability: 100000 Piece/Pieces Month
Detail Information
Place of Origin:
Sichuan China
Certification:
ISO9001:2008
Head Diameter:
3-35mm
Shank Diameter:
3, 6.8mm
Speed:
8000-20000 Rpm
Grain Size:
0.3/0.6/0.8/1.2/2/4 μm
Head Material:
Tungsten Carbide
Shank Material:
Steel
Packaging Details:
Plastic box in Standard export carton
Highlight:

flame shaped finishing bur

,

rotary deburring bits

Product Description
Product Overview

Weld rough edges and polish with the Flame Shape Carbide Burr — a high-performance rotary tool designed for precision deburring, shaping, and surface finishing across demanding industrial applications.

Type B solid carbide rotary burr with flame-shaped head for deburring and grinding metal surfaces
Specifications
Product Name Factory supply power tool parts Carbide Rotary Burr, rotary file for boating industry
Head Shape A, B, C, D, E, F, G, H, I, J, K, L, M, N
Material Head is carbide; shank is steel
Tooth Type Coarse tooth, standard tooth, general purpose tooth, special tooth, rhombic tooth, discontinuous tooth
Cutting Flute Single flute, double flute, coarse flute
Tool Speed 8,000–20,000 rpm
Grain Size (µm) 0.3 / 0.6 / 0.8 / 1.2 / 2 / 4
Application Widely used in machining iron, steel casting, carbon steel, alloy steel, stainless steel, hardened steel, copper, aluminium, and more
Recommended Grade
  • YG8 and YG10X for carbide head
  • Steel for shank diameter
Size Range
  • Head diameter: 3–35 mm
  • Shank diameter: 3 mm, 6 mm, 8 mm
  • Increased length options available
Tolerances
  • Head diameter: +0.3 to +0.5 mm
  • Head cutting part: +0.5 to +1.0 mm
  • Shank diameter: +0 to +0.04 mm
  • Total length: ±0.1 mm
Key Features & Applications
  • High-performance tungsten carbide rotary burrs deliver maximum cutting edge stability with simultaneous high tenacity of the cutting edge.
  • Ideal for shaping, smoothing, and material removal.
  • Suitable for hardened steel, stainless steel, cast iron, nonferrous metals, fired ceramics, plastic, and hard wood — especially materials with hardness above HRC70.
  • Typical operations include deburring, breaking edges, trimming, processing welding seams, and surface finishing.
