C Type Cylindrical Tungsten Steel Grinding Head

100 Pieces
MOQ
USD1-10 Piece
Price
C Type Cylindrical Tungsten Steel Grinding Head
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Carbide Burrs
Shape: Cylindrical
Grade: YG8
Shank: 6MM
OEM/ODM: Available
Shank Length: 45MM
Port: Chengdu/Shanghai/Guangzhou
High Light:

Cylindrical Tungsten Steel Grinding Head

,

YG8 Tungsten Steel Grinding Head

,

C Type Carbide Ball Burr

Basic Infomation
Place of Origin: Sichuan China
Brand Name: KTS
Certification: ISO9001:2008
Model Number: C
Payment & Shipping Terms
Packaging Details: Plastic capsule
Delivery Time: 7-30days
Payment Terms: T/T
Supply Ability: 250000 Piece/Pieces per Month
Product Description

C Type Cylindrical Tungsten Steel Grinding Head



 Double slot:
High-performance tungsten carbide rotary file with cross teeth. Compared with single tooth, cross tooth has higher cutting ability. This is especially beneficial for materials that are difficult to cut. Application field: Used in high alloy steel, stainless steel, acid-resistant steel, heat-resistant steel, die-casting parts and plastics. Deburring, edge breaking, trimming, welding seam processing, surface treatment.



 Feature:
1.Tungsten carbide grinding heads can be used to process metals such as cast iron, cast steel, carbon steel, alloy steel, stainless steel, copper, aluminum, and non-metals such as marble, jade, and bones. The processing hardness is as high as HRC58-60.
2.The leaf handle wheel can be replaced, no dust pollution, processing various high-precision mold cavities. The production efficiency is high, and the processing efficiency is several times higher than that of a file, and nearly ten times higher than that of a small wheel handle.
3.Suitable for woodworkers and hobbyists who often clean welds or metal processing. Easy to master and use. The unique tooth angle prevents chipping.
4.Mainly used for grinding channel impellers, cleaning pipes, finishing and reaming the inner surface of machinery, metal and non-metal processing and engraving.



Technical date

S.N. MATERIAL
1a Steel
1b Hard steels
2 Stainless steel
3 Cast iron
4 Titanium
5 Nickel
6 Copper/Copper alloys
7 Aluminum
8 Plastics
9 Cement



Guide to running speeds

mat nr.

MAX RPM

3mm/0.123"

90,000

6mm/0.250"

50,000

10mm/0.375"

40,000

12mm/0.500"

35,000

16mm/0.625'

25,000

1a 60,000-80,000 35,000-45,000 22,500-35,000 20,000-30,000 15,000-20,000
1b 60,000-80,000 30,000-45,000 19,000-30,000 15,000-22,500 12,000-18,000
2 60,000-80,000 30,000-45,000 19,000-30,000 15,000-22,500 12,000-18,000
3 45,000-80,000 22,500-45,000 15,000-35,000 11,000-30,000 9,000-20,000
4 60,000-80,000 30,000-45,000 19,000-30,000 15,000-22,500 12,000-18,000
5 60,000-80,000 30,000-45,000 19,000-30,000 15,000-22,500 12,000-18,000
6 45,000-80,000 22,500-45,000 15,000-35,000 11,000-30,000 3,000-20,000
7 30,000-80,000 15,000-45,000 10,000-35,000 7,000-30,000 6,000-20,000
8 30,000-80,000 15,000-45,000 10,000-35,000 7,000-30,000 6,000-20,000
9 60,000-80,000 30,000-45,000 19,000-30,000 15,000-22,500 12,000-18,000
