10pcs Set 1/8inch Shank Diameter Tungsten Carbide Rotary Burr and Cutter Files for Precision Metalworking

Brand Name:	KING TOOLS
Model Number:	SA/AC/SD/SE/SF/SG/SH/SL/SM/SN
MOQ:	50
Price:	CN¥5.51-11.08

Detail Information

Product Description

Detail Information

Place of Origin:

Sichuan, China

Shank Diameter:

1/8inch (3mm)

Head Diameter:

3-25 Mm

Head Length:

6-36 Mm

Overall Length:

38-81mm

Material:

Tungsten Carbide

Shank Hardness:

HRA 89-92.5

Tool Speed:

15000-45000 Turn/min

Suggested RPM:

25000-50000, Max 70000

Cutter Pattern:

Double Cut (Single/Aluma Available)

Quantity Per Set:

10pcs

Head Hardness:

90-91HRA

Chipbreaker Type:

Single/Double/Aluma/Diamond Cut

Product Process:

CNC

Grade:

YG6, YG8, YG8C, YG11C, YG15C

Dimension:

3*6mm/0.12*0.24 Inch

Highlight:

1/8inch Shank Diameter Carbide Rotary Burr

Tungsten Carbide Material Rotary Cutter Files

10pcs Set Tungsten Carbide Burr

Product Description

Product Overview

Product Name	10pcs 1/8" Shank Dia Tungsten Carbide Rotary File Burr Cutter 3×6 mm Porting Tools
Brand	KINGTOOLS
Material	Pure Tungsten Carbide
Shank Hardness	HRA 89-92.5
Shank Diameter	3mm/6mm/8mm/10mm/12mm/14mm/16mm...
Speed	15,000-45,000 RPM
Grade	YG6, YG8, YG8C, YG11C, YG15C...
Certificate	ISO9001:2008
Model	Customized carbide burrs
MOQ	2 Piece
Free Sample	Provide Free shipping

Product Specifications

10pcs 3×6mm Carbide Burr Set

Custom configurations available: 10pcs 2.35×6mm, 20pcs 3×3mm, 10pcs 3×4mm, 10pcs 3×5mm carbide burr sets

Material: Tungsten Steel Hard Carbide
Cutter Pattern: Double Cut (aluminum cut / single cut available)
Suitable for: Drilling, Metal Carving, Engraving, Polishing
Dimensions: 3×6mm / 0.12×0.24 inch (Approx.)
Suggested RPM: 25,000-50,000, Max RPM 70,000
Hardness: HRA ≥ 85
Quantity: 10pcs/Set in storage box

Our carbide bur line includes more than 175 individual burs and various kit configurations. These carbide burs are used across multiple industries including automotive, aerospace, foundry, power station, and engineering for mold and pattern making, die sinking, tool making, and maintenance applications.

Cut Type Applications

Single-cut burs: General purpose work with good material removal
Double-cut burs: Produce smaller chips for greater operator control on stainless steels and ferrous materials
Aluma-cut burs: Wide flute design for easy stock removal without loading on nonferrous and soft materials
Standard-cut burs: Widely used with fine finish results

Product Gallery

Burr Types & Specifications

Name	Type	Cut	Material	Process	Hardness	LOGO
Cylindrical	A	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Cylindrical End Cut	B	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Cylindrical Radius End	C	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Ball Shape	D	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Oval	E	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Tree Shape Radius End	F	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Tree Pointed Ends	G	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Flame Shape	H	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Cone Shape With 60°	J	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Cone Shape With 90°	K	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Taper Radius End	L	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Cone	M	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Inverted Cone	N	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
Disc Type	W	Standard/Single/Double/Aluma	Tungsten carbide/YG7/TCT	CNC	90-91HRA	available
