Carbide rotary burr, also known as cemented carbide high-speed assorted milling cutter, cemented carbide mold milling cutter, etc., used with high-speed electric grinder or pneumatic tool.
Technical date
|
S.N. |
MATERIAL |
|
1a |
Steel |
|
1b |
Hard steels |
|
2 |
Stainless steel |
|
3 |
Cast iron |
|
4 |
Titanium |
|
5 |
Nickel |
|
6 |
Copper/Copper alloys |
|
7 |
Aluminum |
|
8 |
Plastics |
|
9 |
Cement |
Guide to running speeds
|
mat nr. MAX RPM |
3mm/0.123" 90,000 |
6mm/0.250" 50,000 |
10mm/0.375" 40,000 |
12mm/0.500" 35,000 |
16mm/0.625' 25,000 |
|
1a |
60,000-80,000 |
35,000-45,000 |
22,500-35,000 |
20,000-30,000 |
15,000-20,000 |
|
1b |
60,000-80,000 |
30,000-45,000 |
19,000-30,000 |
15,000-22,500 |
12,000-18,000 |
|
2 |
60,000-80,000 |
30,000-45,000 |
19,000-30,000 |
15,000-22,500 |
12,000-18,000 |
|
3 |
45,000-80,000 |
22,500-45,000 |
15,000-35,000 |
11,000-30,000 |
9,000-20,000 |
|
4 |
60,000-80,000 |
30,000-45,000 |
19,000-30,000 |
15,000-22,500 |
12,000-18,000 |
|
5 |
60,000-80,000 |
30,000-45,000 |
19,000-30,000 |
15,000-22,500 |
12,000-18,000 |
|
6 |
45,000-80,000 |
22,500-45,000 |
15,000-35,000 |
11,000-30,000 |
3,000-20,000 |
|
7 |
30,000-80,000 |
15,000-45,000 |
10,000-35,000 |
7,000-30,000 |
6,000-20,000 |
|
8 |
30,000-80,000 |
15,000-45,000 |
10,000-35,000 |
7,000-30,000 |
6,000-20,000 |
|
9 |
60,000-80,000 |
30,000-45,000 |
19,000-30,000 |
15,000-22,500 |
12,000-18,000 |
Advantage
1. It can process metals such as cast iron, cast steel, carbon steel, alloy steel, stainless steel, copper, aluminum, and non-metals such as marble, jade, and bone. Processing hardness can reach HRA≥85.
2. Basically, it can replace the small grinding wheel with handle, and there is no dust pollution.
3. High production efficiency. The processing efficiency is more than ten times higher than that of manual files, and nearly ten times higher than that of small grinding wheels with handles.
4. Good processing quality and high finish. It can process a variety of high-precision mold cavities.
5. Long service life. The durability is ten times higher than that of high-speed steel cutting tools, and more than 200 times higher than that of small grinding wheels.
6. Easy to master, simple to use, safe and reliable.
7. The comprehensive processing cost can be reduced dozens of times.
Features available across the range include:
Shake
Ball Nose Geometry
Brazing
